Description
Cabinet Specs
- Finish – Stunning 2 Pak Graphite Automotive paint finish with Matte clear coat
- Construction – 18 mm MDF
- Power: 500 Watts RMS @ 4 ohms
- Power Amp: State of the art D Class switch mode power amp with heat sink plate mounted into the side of the cabinet
- Frequency response: down to 30Hz HPF (will actually go to 28hz)
- Crossover points: Selectable LPF switch 80Hz or 50Hz (custom options available)
- Driver: Custom made 10″ driver with Aluminium cast frames, specially formulated Kevlar impregnated eucalyptus pulp cone
- Voice coil: 76mm / 3 inches
- Magnet: Massive Ferrite
- Control plate: Black Steel
- Universal Mains Power in: Standard IEC
DSP & Control Plate Features
- Inputs: XLR Analogue Balanced
- DSP – 192K SHARC processing
- USB connector for WJ Audio use only. Used for software updates
- 3 Toggle switches with selections (centre position is Flat – undeniably accurate)
- Inputs: XLR Analogue (center position mutes monitor)
- Room 1: Inactive. For future development /
Room 2: SoundID Reference calibration (preloaded with test profile) - Room 3: Crossover selection 30Hz HPF
- LED on Control Panel for power operation
Single Monitor Dimensions:
- 33 x 45 x 50 cm
- 13 x 18 x 20 inches
Single Monitor Weight:
- 23.5 kg
- 52.5 lbs
Shipping Dimensions & Weights (shipped as single in carton):
- 51 x 40 x 58 cm
- 20.5 x 15.8 x 22.3 inches
- 24.5kg
- 54lbs
